ADL-63153TL
635nm 15mW Laser Diode, 50°C Reliable Operation
FEATURES
APPLICATION
Absolute maximum ratings
| Parameter | Symbol | Condition | Rating | Unit |
|---|---|---|---|---|
| Light output power | Po | CW | 17 | mW |
| Case temperature | Tc | -10~+50 | °C | |
| Storage temperature | Ts | -40~+85 | °C |
Electrical and optical characteristics (Tc=25∘C)
| Parameter | Symbol | Min. | Typ. | Max. | Unit | Conditions |
|---|---|---|---|---|---|---|
| Peak wavelength | λ | 630 | 636 | 640 | nm | |
| Threshold current | Ith | - | 33 | 45 | mA | |
| Operation current | Iop | - | 66 | 80 | mA | |
| Operating voltage | Vop | - | 2.3 | 2.6 | V | |
| Differential efficiency | η | 0.3 | 0.45 | 0.7 | mW/mA | |
| Monitor current | Im | 0.1 | 0.2 | 0.4 | mA | |
| Parallel divergence angle | θ// | 6.0 | 7.5 | 10 | deg. | |
| Perpendicular divergence angle | θ⊥ | 30 | 33 | 38 | deg. | |
| Parallel FFP deviation angle | Δθ// | -2 | 0 | +2 | deg. | |
| Perpendicular FFP deviation angle | Δθ⊥ | -2 | 0 | +2 | deg. | |
| Emission point accuracy | ΔxΔyΔz | -80 | 0 | +80 | um |
