ADL-65052TL
650nm 5mW 50°C Laser Diode, Low Current Operation
FEATURES
- Low operating current
- High efficiency
- FFP single lateral mode
APPLICATION
- Laser pointers
- Industrial laser markers / measuring instruments
- Barcode readers
ADL-65052TL
650nm 5mW 50°C Laser Diode, Low Current Operation
FEATURES
APPLICATION
Absolute maximum ratings
| Parameter | Symbol | Condition | Rating | Unit |
|---|---|---|---|---|
| Light output power | Po | CW | 7 | mW |
| Case temperature | Tc | - | -10~+50 | °C |
| Storage temperature | Ts | - | -40~+85 | °C |
Electrical and optical characteristics (Tc=25∘C)
| Parameter | Symbol | Min. | Typ. | Max. | Unit | Conditions |
|---|---|---|---|---|---|---|
| Peak wavelength | λ | 645 | 655 | 660 | nm | Po=5mW |
| Threshold current | Ith | - | 15 | 20 | mA | |
| Operation current | Iop | - | 20 | 22 | mA | |
| Operating voltage | Vop | - | 2.2 | 2.5 | V | |
| Differential efficiency | η | 0.5 | 1.0 | 1.4 | mW/mA | |
| Monitor current | Im | 0.05 | 0.1 | 0.3 | mA | |
| Parallel divergence angle | θ// | 6 | 8 | 12 | deg. | |
| Perpendicular divergence angle | θ⊥ | 24 | 27 | 32 | deg. | |
| Parallel FFP deviation angle | Δθ// | -3 | 0 | +3 | deg. | |
| Perpendicular FFP deviation angle | Δθ⊥ | -3 | 0 | +3 | deg. | |
| Emission point accuracy | ΔxΔyΔz | -80 | 0 | +80 | um |
