ADL-66505TL
660nm 50mW Laser Diode
FEATURES
- Highly reliable / COD free
- High power operation
- High efficiency
APPLICATION
- High power Laser modules
- Industrial laser markers/measuring instruments
- Medical application
ADL-66505TL
660nm 50mW Laser Diode
FEATURES
APPLICATION
Absolute maximum ratings
| Parameter | Symbol | Condition | Rating | Unit |
|---|---|---|---|---|
| Light output power | Po | - | 55 | mW |
| Case temperature | Tc | - | -10~+60 | °C |
| Storage temperature | Ts | - | -40~+85 | °C |
Electrical and optical characteristics (Tc=25∘C)
| Parameter | Symbol | Min. | Typ. | Max. | Unit | Conditions |
|---|---|---|---|---|---|---|
| Peak wavelength | λ | 653 | 660 | 667 | nm | Po=50 mW |
| Threshold current | Ith | - | 45 | 60 | mA | Po=50 mW |
| Operation current | Iop | - | 95 | 120 | mA | Po=50 mW |
| Operating voltage | Vop | 2.0 | 2.5 | 3.0 | V | Po=50 mW |
| Differential efficiency | η | 0.7 | 1.0 | 1.4 | mW/mA | Po=45-50mW |
| Monitor current | Im | 0.05 | 0.2 | 0.5 | mA | Po=50mW,VRD=5V |
| Parallel divergence angle | θ// | 6 | 9 | 13 | deg. | Po=50 mW |
| Perpendicular divergence angle | θ⊥ | 13 | 17 | 22 | deg. | Po=50 mW |
| Parallel FFP deviation angle | Δθ// | -3.0 | 0 | +3.0 | deg. | Po=50 mW |
| Perpendicular FFP deviation angle | Δθ⊥ | -3.0 | 0 | +3.0 | deg. | Po=50 mW |
| Emission point accuracy | ΔxΔyΔz | -80 | 0 | +80 | um | Po=50 mW |
