ADL-80V03TL
808nm 0.5W Laser Diode
FEATURES
- Highly reliable
- Higher Power
APPLICATION
- Industrial
- Biomedical
- Scientific
ADL-80V03TL
808nm 0.5W Laser Diode
FEATURES
APPLICATION
Absolute maximum ratings
| Parameter | Symbol | Condition | Rating | Unit |
|---|---|---|---|---|
| Light output power | Po | - | 550 | mW |
| Case temperature | Tc | - | -10~+50 | °C |
| Storage temperature | Ts | - | -40~+85 | °C |
Electrical and optical characteristics (Tc=25∘C)
| Parameter | Symbol | Min. | Typ. | Max. | Unit | Conditions |
|---|---|---|---|---|---|---|
| Peak wavelength | λ | 798 | 808 | 818 | nm | |
| Threshold current | Ith | - | 320 | 450 | mA | |
| Operation current | Iop | - | 800 | 1000 | mA | |
| Operating voltage | Vop | - | 1.9 | 2.5 | V | |
| Differential efficiency | η | 0.7 | 1.1 | 1.4 | mW/mA | |
| Monitor current | Im | 0.5 | - | 3 | mA | |
| Parallel divergence angle | θ// | - | 7 | 12 | deg. | |
| Perpendicular divergence angle | θ⊥ | 30 | 35 | 40 | deg. |
