ADL-85051SL
850nm 5mW Laser Diode
FEATURES
- Low operating current
- Cost effective
APPLICATION
- Bar-code scanner
- Laser printer
- Defense
ADL-85051SL
850nm 5mW Laser Diode
FEATURES
APPLICATION
Absolute maximum ratings
| Parameter | Symbol | Condition | Rating | Unit |
|---|---|---|---|---|
| Light output power | Po | CW | 7 | mW |
| Case temperature | Tc | - | -10~+50 | °C |
| Storage temperature | Ts | - | -40~+85 | °C |
Electrical and optical characteristics (Tc=25∘C)
| Parameter | Symbol | Min. | Typ. | Max. | Unit | Conditions |
|---|---|---|---|---|---|---|
| Peak wavelength | λ | 840 | 845 | 850 | nm | Po=5mW |
| Threshold current | Ith | - | 19 | 25 | mA | |
| Operation current | Iop | - | 26 | 35 | mA | Po=5mW |
| Operating voltage | Vop | - | 1.8 | 2.0 | V | Po=5mW |
| Monitor current | Im | 0.4 | 0.6 | 0.8 | mA | |
| Parallel divergence angle | θ// | 6 | 9 | 14 | deg. | Po=5mW |
| Perpendicular divergence angle | θ⊥ | 27 | 32 | 36 | deg. | Po=5mW |
| Parallel FFP deviation angle | Δθ// | -3 | 0 | +3 | deg. | Po=5mW |
| Perpendicular FFP deviation angle | Δθ⊥ | -3 | 0 | +3 | deg. | Po=5mW |
| Emission point accuracy | ΔxΔyΔz | -80 | 0 | +80 | um | Po=5mW |
