ADL-63054TL

ADL-63054TL

635nm 5mW Laser Diode, 50℃ Reliable Operation

FEATURES

  1. High assembly accuracy
  2. High monitor current
  3. High temperature operation

APPLICATION

  1. High precision measuring instruments
  2. High precision industrial laser markers
  3. Survey and engineering instruments

DOWNLOAD

Absolute maximum ratings

Parameter Symbol Condition Rating Unit
Light output power Po CW 7 mW
Case temperature Tc - -10~+50 °C
Storage temperature Ts - -40~+85 °C

Electrical and optical characteristics (Tc=25∘C)

Parameter Symbol Min. Typ. Max. Unit Conditions
Peak wavelength λ 630 635 640 nm
Threshold current Ith - 24 30 mA
Operation current Iop - 33 40 mA
Operating voltage Vop - 2.2 2.5 V
Differential efficiency η 0.4 0.6 0.8 mW/mA
Monitor current Im 0.1 0.15 0.3 mA
Parallel divergence angle θ// 6 7.5 11 deg.
Perpendicular divergence angle θ 30 33 40 deg.
Parallel FFP deviation angle Δθ// -2 0 +2 deg.
Perpendicular FFP deviation angle Δθ⊥ -2 0 +2 deg.
Emission point accuracy ΔxΔyΔz -60 0 +60 um
